PVC Insulated Cables

Product: BV Hard wire for fixed arrangement (ZR-BV、NH-BV)

Academic name: Copper core PVC insulated wire

Implementation standards: Copper core PVC insulated wire

Model: BV

Conductor material: Copper oxide-free core (copper content: 99.9%)

Number of cores: single core

Insulation materials: PVC

Rated voltage:

60227IEC01(BV)-450/750V

60227IEC05（BV）-300/500V

60227IEC07(BV-90)-300/500V

Colour: red, yellow, blue, green, black, white, yellow-green colour

Scope of application: this product is suitable for AC rated voltage of 450 / 750v and below. It is required for fixed laying of electrical, instrumentation, telecommunication equipment, power plant and lighting line in flame retardant field.

Features:

The allowable working temperature of all models of cables should not exceed 70 ℃. The laying temperature of cables should be no less than 0 ℃, and the outer diameter (D) is less than 25mm. The allowable bending radius of cables should be no less than 4D, and the allowable bending radius of cables should be less than 6D., if the outer diameter (D) is 25mm or above.
BV wire full name for the copper core PVC insulated wire, that is, general-purpose single-core hard-conductor non-sheathed cable, which is used in our daily lives ordinary insulated wire, home improvement wire, is the most commonly used wire type. With anti-acid, oil, moisture, mildew and other characteristics.
